U.P.V.C

Al-Sharifin Plastic Pipe Manufacturing Company is one of the companies producing and specializing in the field of…U.P.V.C pipes of all different types are one of the monuments of the pipe industry in Egypt. Al-Sharifin Plastic Pipe Manufacturing Company was established in 2006 on an area of ​​5,000 square metres. The pipes are produced from polyvinyl chloride, which is superior to other materials in the manufacture of pipes used for various purposes, water networks, sanitation, ventilation, and telephone and electricity cable covering pipes, according to several specifications. It is global

01
German
German specifications 8061 - 8062 DIN
02
Egyptian standard
Egyptian standard specifications m. BC 1717. For sanitation And Egyptian BC 848. For drinking water and irrigation
03
British
British Specification BS 3506
04
Egyptian Telecommunications Company
It is done on plastering machines to ensure the quality and safety of the weld.

Delivery method

05
American
Microscopic examination of the welding area and ensuring that internal stresses are removed.
01
With adhesive for diameters from 20 to 90 mm
02
With rubber rings from 10 - 800 mm
03
The length of the pipe is 6 meters, including the head
04
Pipe color is gray upon request

Well pipes

Well pipes are produced according to German specifications 8062 – 8061 – DIN 4925.

These pipes are characterized by the following

  • It has a smooth surface that facilitates the transfer of liquids
  • Easy to install manually
  • Resistant to alkalis, salts and soil chemicals
  • Pipes pressure 10 bar and 16 bar

Types of pipes according to the method of connection (connection)

  • Perforated pipes with threaded heads
  • Filtered wire with a threaded head

Pipes are produced using the latest machines with modern technology that are controlled remotely at all stages of production to ensure the safety of the product and its compliance with international specifications.There is continuous monitoring of the pipes by a full team of specialists in monitoring production and laboratory affairs, as we have all the devices that allow us to ensure that the production conforms to the applicable local and international specifications, as well as the mechanical and chemical properties.
There is continuous monitoring of the pipes by a full team of specialists in monitoring production and laboratory affairs, as we have all the devices that allow us to ensure that the production conforms to the applicable local and international specifications, as well as the mechanical and chemical properties.

– We are fully prepared to provide technical consultations and expertise in the field of pipe installation.

Normal Outside Diameter mm
Outer diameter		 Socket Depth mm
Inner depth area		 Class II 4 BAR Class III 6 BAR Class IV 10 BAR Class V 16 BAR
No. Thick of wall mm
Wall thickness		 Nom.wt kg/m
Meter weight		 No. Thick of wall mm
thickness		 Nom.wt kg/m
Meter weight		 No. Thick of wall mm
Wall thickness		 Nom.wt kg/m
Meter weight		 No. Thick of wall mm
Wall thickness		 Nom.wt kg/m
Meter weight
20 1.5 0.137
25 1.5 0.174 1.9 0.212
32 1.8 0.264 2.4 0.342
40 1.8 0.334 1.9 0.35 3 0.525
50 75 1.8 0.422 2.4 0.552 3.7 0.809
63 100 1.9 0.562 3 0.854 4.7 1.289
75 110 1.8 0.642 2.2 0.782 3.6 1.22 5.6 1.82
90 110 1.8 0.774 2.7 1.13 4.3 1.75 6.7 2.61
110 115 2.2 1.16 3.2 1.64 5.3 2.61 8.2 3.9
125 120 2.5 1.48 3.7 2.13 6 3.34 9.3 5.01
140 125 2.8 1.84 4.1 2.65 6.7 4.18 10.4 6.27
160 132 3.2 2.41 4.7 3.44 7.7 5.47 11.9 8.17
180 145 3.6 3.02 5.3 4.37 8.6 6.88 13.4 10.4
200 145 4 3.7 5.9 5.37 9.6 8.51 14.9 12.8
225 152 4.5 4.7 6.6 6.76 10.8 10.8 16.7 16.1
250 160 4.9 5.65 7.3 8.31 11.9 13.2 18.6 19.9
280 170 5.5 7.11 8.2 10.4 13.4 16.6 20.8 24.9
315 180 6.2 9.02 9.2 13.2 15 20.9 23.4 31.5
355 180 7 11.4 10.4 16.7 16.9 26.5 26.3 39.9
400 200 7.9 14.5 11.7 21.1 19.1 33.7 29.7 50.8
450 290 8.9 18.3 13.2 26.8 21.5 42.7
500 330 9.8 22.4 14.6 32.9 23.9 52.6
560 330 11 28.1 16.4 41.4 26.7 65.8
630 360 12.4 35.7 18.4 52.2 30 83.2
710 380 14 45.3 20.7 66.1
800 410 15.7 57.2 23.3 83.9
